Recoil Technologies Is The Leading Supplier For The Armed Forces For Bolt Carriers. Tried & True This .308 WIN/6.5 Creedmoor/.243 WIN Bolt Carrier Group Is Engineered & Designed To The Highest Tolerances & Military Specifications. The superior QPQ Nitride Ion Finish Ensures Long Term Durability & Lubrication.
This Bolt Carrier Is The Very Best You Can Get For Your LR-308 Platform Gun.
Most Of the .308 AR Rifles On The Market Today Are The LR-308 Platform or DPMS Style Platform.
Certified For Use By US Military & Law Enforcement
Carrier:
LR-308 Carrier DPMS Style compatible
8620 heat-treated (case hardened to SAE-AMS-6875). QPQ / nitride / melonite coated
Bolt:
9310 heat-treated (case hardened to SAE-AMS-6875) with additional cryo freeze for extra strength.
Shot peened precision ground diameters.
Magnetic particle inspected to ASTM E1444 aircraft quality inspection procedure for molecular soundness and longer life of the Bolt.
Extractors:
Aircraft quality alloy steel shot-peened.
Heat treated to military drawing specification SAE-AMS-6875.
Phosphated to 5.3.1.3 of MIL-STD-171.
Gas key:
Gas key bolt, grade 8 fully knurled.
Gas key, aircraft-quality steel heat treated to SAE-AMS-6875 QPQ HT Process.
Cam pin:
Precision machined.
Heat treated to SAE-AMS-6875.
Phosphated to 5.3.1.3 of MIL-STD-171
Firing pin:
Machined and precision ground for accuracy
Heat treated to military drawing specification per SAE-AMS-6875
Chrome lined per 1.2.2 of mil-std-171
Firing pin retaining pin:
Unique designed custom steel pin contouring the carrier body.
Heat treated to SAE-AMS-6875.
Phosphated to 5.3.1.3 of MIL-STD-171.
Ejector:
Precision machined.
Heat Treated to SAE-AMS-6875.
Phosphated to 5.3.1.3 of MIL-STD-171.
Gas rings:
Stainless Steel per Mil-Spec 3 Piece design.
Enhanced extractor springs
SPECIFICATIONS:
Brand: Recoil Technologies
Caliber: .308 WIN/ 6.5 Creedmoor/.243 WIN
Bolt Head Finish: QPQ Nitride
Bolt Head Material: 9310 Alloy Steel
Carrier Finish: QPQ Nitride
Carrier Material: 8620 Alloy Steel
Magnetic Particle Inspect (MPI): Yes
Platform: LR-308
Forward Assist Notches: Yes
Style: Standard
Color: Black
Full Auto Compatible: No
To assure the highest degree of consistency and reliability, we invest in premium extractor springs from Tactical Springs LLC / Sprinco USA along with a Mil-Spec Black Viton Extractor O-Ring per MIL-R-83248C. The springs are constructed from Chrome Silicon wirestock, a high tensile strength alloy ideally suited for high heat and high cyclic rate applications. The springs are heat treated, stress relieved, moly-plated, and most importantly, Cryogenic Processed post winding. While Cryogenic Processing typically extends the duty cycle of Chrome Silicon springs 3X - 7 X, these extractor springs have proven to surpass that multiplier. Unlike Music Wire or 17-7PH Stainless extractor springs which can require replacement at 2,500 to 5,000 round intervals for maximum reliability, this is likely to be the only extractor spring you'll require for the life of the bolt! Numerous accounts have been recorded from customers with round counts in excess of 100,000 cycles on a single spring and O-ring with no noticeable degradation in performance. You'll go through a number of barrels and extractors along the way to reaching that level, but the spring and O-rings can stay along for the ride.
